Apocalypse AP-M67AC PRO | Mid-Range Speakers (Pair)

Manual AP-M67AC PRO

AP-M67AC PRO Midrange Speaker Specifications

• Type: Midrange

• Size: 6.7"

• Frequency Response: 160 – 15,000 Hz

• Package Quantity: Pair

Power Handling:

• RMS Power: 300 W

• Max Power: 600 W

Build & Components:

• Voice Coil Size: 1.75"

• Voice Coil Wire: CCAW (Copper-Clad Aluminum Wire)

• Cone Material: Paper

• Surround: Cloth

• Magnet Type: Ferrite

• Frame: Cast Aluminum

Performance Characteristics:

• Impedance: 4 Ohm

• Sensitivity (SPL): 102 dB

• Resonance Frequency (Fs): 187 Hz

• Total Q Factor (Qts): 0.44

• BL (Magnetic Force): 9.72

• Vas (Equivalent Air Volume): 2.34 L

Mounting Dimensions:

• Mounting Depth: 3.1"

• Cut-Out Diameter: 6.14"

Shipping Weight:

• Gross Weight: 16 lb (7.1 kg)
